Cablu Fibra Optica FXY - 4F-12F

MAX. TENSION STRENGTH : 1000 Newton

CRUSH RESISTANCE : 450 Newton/10 cm

MINIMUM BENDING RADIUS : 85mm

MAX. OPERATING/ INSTALLATION TEMPERATURE : - 30 °C to + 70 °C

SPAN LENGTH : 50m

NO. OF FIBRES 4 F 12F

NO OF TUBES/NO OF FILLER 1/0

TYPE OF FIBRE SM G652 D

LOOSE TUBE DIAMETER 2.0 mm Nominal 2.0 mm Nominal

STRENGTH MEMBER 2*1.0 mm FRP & GLASS YARN REINFORCEMENT

SEQUENCE OF TUBE NATURAL

COLOUR OF FIBRE BLUE, ORANGE, GREEN, BROWN BLUE, ORANGE, GREEN, BROWN, GREY, WHITE, RED, BALCK, YELLOW, VIOLET, PINK, AQUA OUTER SHEATH MATERIAL PE OUTER SHEATH THICKNESS 0.5mm -2.2 mm nominal

OUTER CABLE DIAMETER 6.4 + 0.2 mm CABLE WEIGHT 36 +3Kg/Km

STANDARD LENGTH AS PER PURCHASE ORDER
